FESCT TA36 600A/100mA Split Core Current Transformer with HY 2.0 | Class 1 Accuracy | 36mm Aperture | for Solar Panels, Energy Monitoring & Industrial Applications
FESCT TA36 600A/100mA Split Core Current Transformer with HY 2.0 | Class 1 Accuracy | 36mm Aperture | for Solar Panels, Energy Monitoring & Industrial Applications

FESCT TA36 600A/100mA Split Core Current Transformer with HY 2.0 | Class 1 Accuracy | 36mm Aperture | for Solar Panels, Energy Monitoring & Industrial Applications

$32.45 $59 -45%

Delivery & Return:Free shipping on all orders over $50

Estimated Delivery:7-15 days international

People:9 people viewing this product right now!

Easy Returns:Enjoy hassle-free returns within 30 days!

Payment:Secure checkout

SKU:40477562

Guranteed safe checkout
amex
paypal
discover
mastercard
visa

Product Description

Fastron Electronics FESCT-TA36-600A/100mA + HY-2.0, 600A/100mA Measurement, Class 1 Split Core CT's, 36mm Aperture

Features

  • Quick Release Split Core System
  • Cable Mount
  • 100mAmp Output
  • Self Powered
  • Rated System Voltage 0.60/3kV
  • 0.9M Flying Leads with HY-2.0 Connector

    Applications

    • Eastron Modular Metering Equipment
    • Energy Monitoring
    • Load Balancing
    • Power Quality Measurements



    Specification
    Fastron Part NumberFESCT-F36-600A/100mA + HY-2.0
    TechnologySplit Core AC Current Transformer
    Ratio600/100mA
    Aperture Sizeø 36 mm
    VA Rating1VA
    Accuracy ClassClass 1
    Output100mA (+20%)
    Isolation3kV (AC, 50Hz, 1 min)
    Bandwidth50-60Hz
    Mounting StyleCable Mount/Busbar Mount
    Operating Temperature Range-15°C / 45°C
    Continuous Current (max)600Amp x 1.2
    Termination Style0.9M Flying leads with HY-2.0 Connector
    Unit Weight170g
    Factory Pack Qty9



    Datasheet
    Application Notes
