300A Split Core Current Transformer (CT) - 100mV Output, Class 1 Accuracy, 32x32mm Aperture with 1M Flying Leads & HY2.0 Connector for Solar Power Monitoring, Energy Metering, and Electrical Load Measurement
300A Split Core Current Transformer (CT) - 100mV Output, Class 1 Accuracy, 32x32mm Aperture with 1M Flying Leads & HY2.0 Connector for Solar Power Monitoring, Energy Metering, and Electrical Load Measurement

300A Split Core Current Transformer (CT) - 100mV Output, Class 1 Accuracy, 32x32mm Aperture with 1M Flying Leads & HY2.0 Connector for Solar Power Monitoring, Energy Metering, and Electrical Load Measurement

$45.37 $82.5 -45%

Delivery & Return:Free shipping on all orders over $50

Estimated Delivery:7-15 days international

People:8 people viewing this product right now!

Easy Returns:Enjoy hassle-free returns within 30 days!

Payment:Secure checkout

SKU:23751925

Guranteed safe checkout
amex
paypal
discover
mastercard
visa

Product Description

Fastron Electronics FESCT-32-300-100mV, 300Amp measurement Split Core CT's, w/1M Flying Leads, HY2.0 Connection, 32x32mm Aperture, 100mV Class 1 Series Current Transformer

Features

  • Quick Release Split Core System
  • 1m Flying Leads
  • Mounting Feet Supplied
  • Self Powered
  • Rated System Voltage 0.60/2kV

    Applications

    • US Based Metering Equipment
    • Energy Monitoring
    • AC Power Control Systems
    • Power Factor Correction
    • Power Quality Measurements



    Specification
    Fastron Part NumberFESCT-32-300-100mV
    TechnologySplit Core AC Current Transformer
    Ratio300/100mV
    Aperture Size32 x 32mm
    VA RatingN/A
    Accuracy ClassClass 1
    Output100mVAC (+20%)
    Isolation3kV (AC, 50Hz, 1 min)
    Bandwidth50-60Hz
    Mounting StyleCable Mount/Busbar Mount
    Operating Temperature Range-15°C / 55°C
    Continuous Current (max)300Amp x 1.2
    Termination Style1M Twisted Pair 0.34mm^2
    Unit Weight350g
    Factory Pack Qty9



    Datasheet
